Flicker-free LED Panel Light

MK-PN015120-RN024-01 (150mm×1195mm)
Feature

Design for residential / commercial lighting and indoor use

UGR<19

SDCM<3

High efficiency

Wattage: 24Watt

Color temperature: CCT 3000K/4000K/5000K/6000K


Color
Description

Construction: Aluminum housing with good heat dissipation + PS diffuser

Mounting: Ceiling mounting / Wall (surface) mounting / suspended mounting


Parameters

Luminous flux: 2000~2400lm

Luminous flux efficacy: 90~100lm/W

Color rendering index: >80

Beam angle: 120°

LED lamp: 2835

Life time: 50000Hours

Input voltage: 220-240VAC 50/60Hz

Power factor: >0.9


Properties

Dimensions: 150mm × 1195mm × 15mm

Luminaire material: 6063 aluminum + PS

Dimming: Non-dimmable

Electrical safety: Class II

IP rating: IP20

Operation temperature: -20°C ~ +45°C



MK-PN030120-RN040-01 (295mm×1195mm)
Feature

Design for residential / commercial lighting and indoor use

UGR<19

SDCM<3

High efficiency

Wattage: 40Watt

Color temperature: CCT 3000K/4000K/5000K/6000K


Color
Description

Construction: Aluminum housing with good heat dissipation + PS diffuser

Mounting: Ceiling mounting / Wall (surface) mounting / suspended mounting


Parameters

Luminous flux: 4000~4500lm

Luminous flux efficacy: 100~105lm/W

Color rendering index: >80

Beam angle: 120°

LED lamp: 2835

Life time: 50000Hours

Input voltage: 220-240VAC 50/60Hz

Power factor: >0.9


Properties

Dimensions: 295mm × 1195mm × 15mm

Luminaire material: 6063 aluminum + PS

Dimming: Non-dimmable

Electrical safety: Class II

IP rating: IP20

Operation temperature: -20°C ~ +45°C



MK-PN060060-SN040-01 (595mm×595mm)
Feature

Design for residential / commercial lighting and indoor use

UGR<19

SDCM<3

High efficiency

Wattage: 40Watt

Color temperature: CCT 3000K/4000K/5000K/6000K


Color
Description

Construction: Aluminum housing with good heat dissipation + PS diffuser

Mounting: Ceiling mounting / Wall (surface) mounting / suspended mounting

Parameters

Luminous flux: 4000~4500lm

Luminous flux efficacy: 100~105lm/W

Color rendering index: >80

Beam angle: 120°

LED lamp: 2835

Life time: 50000Hours

Input voltage: 220-240VAC 50/60Hz

Power factor: >0.9


Properties

Dimensions: 595mm × 595mm × 15mm

Luminaire material: 6063 aluminum + PS

Dimming: Non-dimmable

Electrical safety: Class II

IP rating: IP20

Operation temperature: -20°C ~ +45°C



MK-PN075075-SN050-01 (750mm×750mm)
Feature

Design for residential / commercial lighting and indoor use

UGR<19

SDCM<3

High efficiency

Wattage: 50Watt

Color temperature: CCT 3000K/4000K/5000K/6000K


Color
Description

Construction: Aluminum housing with good heat dissipation + PS diffuser

Mounting: Ceiling mounting / Wall (surface) mounting / suspended mounting

Parameters

Luminous flux: 5000~5500lm

Luminous flux efficacy: 100~105lm/W

Color rendering index: >80

Beam angle: 120°

LED lamp: 2835

Life time: 50000Hours

Input voltage: 220-240VAC 50/60Hz

Power factor: >0.9


Properties

Dimensions: 750mm × 750mm × 15mm

Luminaire material: 6063 aluminum + PS

Dimming: Non-dimmable

Electrical safety: Class II

IP rating: IP20

Operation temperature: -20°C ~ +45°C
